MMBTA92L, SMMBTA92L,

MMBTA93L

Features

• S Prefix for Automotive and Other Applications Requiring Unique

Site and Control Change Requirements; AEC−Q101 Qualified and

PPAP Capable

• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS

Compliant

Collector−Emitter Voltage VCEO −300 −200 Vdc

Collector−Base Voltage VCBO −300 −200 Vdc

Emitter−Base Voltage VEBO −5.0 −5.0 Vdc

Collector Current — Continuous IC −500 mAdc

MMBTA92L, SMMBTA92L = 2D; MMBTA93LT1 = 2E

Total Device Dissipation FR−5 Board

(Note 1) TA = 25°C

Derate above 25°C

PD 225 1.8 mWmW/°C

Thermal Resistance, Junction to Ambient RJA 556 °C/W

Total Device Dissipation (Note 2)

Alumina Substrate,(2) TA = 25°C

Derate above 25°C

PD 300 2.4mWmW/°C

Thermal Resistance, Junction to Ambient RJA 417 °C/W

Junction and Storage Temperature TJ, Tstg −55 to+150°C

MMBTA92LT1G SOT−23 (Pb−Free) SOT−23 (TO−236AF) CASE 318 STYLE 6 3000 / Tape & Reel

SMMBTA92LT1G SOT−23 (Pb−Free)3000 / Tape & Reel

MMBTA92LT3G SOT−23 (Pb−Free)10000 / Tape & Reel

SMMBTA92LT3G SOT−23 (Pb−Free)10000 / Tape & Reel
