E50S8-512-2-2-24奥托尼克斯Autonics增量式编码器

Autonics编码器E50S8系列奥托尼克斯Autonics增量式旋转编码器

我公司*代理奥托尼克斯Autonics编码器

● 体积小, 重量轻, 安装方便，可在狭小空间安装。● 外径Φ50mm ，止口Φ30mm ，D 型切口，轴径Φ8mm.

● 适用于精密工作环境.● 电缆侧出.● 电源电压：5VDC ，12-24VDC ±5%

● 信号输出：A 、B 信号

A 、B 、Z 信号

A 、A 的反相信号、B 、B 反相信号,

A 、A 的反相信号、B 、B 反相信号, Z 、Z 的反相信号。

● 消耗电流: ≤120mA ● 输出波形: 方波

● 载空比:0.5T ±0.1T● *大机械转速:6000rpm

● *护: *水, *油, *尘IP54

详情联系：：左蓉 QQ:1922471169 旺旺：hcdqzr

公司网址：https://hcdqzr.cn.alibaba.com/

三相输出	三相输出	三相输出	六相输出
E50S8-10-3-1-24 E50S8-20-3-1-24 E50S8-30-3-1-24 E50S8-40-3-1-24 E50S8-50-3-1-24 E50S8-60-3-1-24 E50S8-100-3-1-24 E50S8-200-3-1-24 E50S8-300-3-1-24 E50S8-360-3-1-24 E50S8-400-3-1-24 E50S8-500-3-1-24 E50S8-512-3-1-24 E50S8-600-3-1-24 E50S8-800-3-1-24 E50S8-1 E50S8-1 E50S8-1200-3-1-24 E50S8- E50S8- E50S8-2 E50S8-2 E50S8-2500-3-1-24 E50S8-3 E50S8-3600-3-1-24	E50S8-10-3-2-24 E50S8-20-3-2-24 E50S8-30-3-2-24 E50S8-40-3-2-24 E50S8-50-3-2-24 E50S8-60-3-2-24 E50S8-100-3-2-24 E50S8-200-3-2-24 E50S8-300-3-2-24 E50S8-360-3-2-24 E50S8-400-3-2-24 E50S8-500-3-2-24 E50S8-512-3-2-24 E50S8-600-3-2-24 E50S8-800-3-2-24 E50S8-1 E50S8-1 E50S8-1200-3-2-24 E50S8- E50S8- E50S8-2 E50S8-2 E50S8-2500-3-2-24 E50S8-3 E50S8-3600-3-2-24	E50S8-10-3-3-24 E50S8-20-3-3-24 E50S8-30-3-3-24 E50S8-40-3-3-24 E50S8-50-3-3-24 E50S8-60-3-3-24 E50S8-100-3-3-24 E50S8-200-3-3-24 E50S8-300-3-3-24 E50S8-360-3-3-24 E50S8-400-3-3-24 E50S8-500-3-3-24 E50S8-512-3-3-24 E50S8-600-3-3-24 E50S8-800-3-3-24 E50S8-1 E50S8-1 E50S8-1200-3-3-24 E50S8- E50S8- E50S8-2 E50S8-2 E50S8-2500-3-3-24 E50S8-3 E50S8-3600-3-3-24	E50S8-10-6-L E50S8-20-6-L E50S8-30-6-L E50S8-40-6-L E50S8-50-6-L E50S8-60-6-L E50S8-100-6-L E50S8-200-6-L E50S8-300-6-L E50S8-360-6-L E50S8-400-6-L E50S8-500-6-L E50S8-512-6-L E50S8-600-6-L E50S8-800-6-L E50S8-1000-6-L E50S8-1024-6-L E50S8-1200-6-L E50S8-1500-6-L E50S8-1800-6-L E50S8-2000-6-L E50S8-2048-6-L E50S8-2500-6-L E50S8-3000-6-L E50S8-3600-6-L
Autonics	Autonics	Autonics	Autonics
Rotary encoder	Rotary encoder	Rotary encoder	Rotary encoder
二相输出	二相输出	二相输出	四相输出
E50S8-10-2-1-24 E50S8-20-2-1-24 E50S8-30-2-1-24 E50S8-40-2-1-24 E50S8-50-2-1-24 E50S8-60-2-1-24 E50S8-100-2-1-24 E50S8-200-2-1-24 E50S8-300-2-1-24 E50S8-360-2-1-24 E50S8-400-2-1-24 E50S8-500-2-1-24 E50S8-512-2-1-24 E50S8-600-2-1-24 E50S8-800-2-1-24 E50S8-1 E50S8-1 E50S8-1200-2-1-24 E50S8- E50S8- E50S8-2 E50S8-2 E50S8-2500-2-1-24 E50S8-3 E50S8-3600-2-1-24	E50S8-10-2-2-24 E50S8-20-2-2-24 E50S8-30-2-2-24 E50S8-40-2-2-24 E50S8-50-2-2-24 E50S8-60-2-2-24 E50S8-100-2-2-24 E50S8-200-2-2-24 E50S8-300-2-2-24 E50S8-360-2-2-24 E50S8-400-2-2-24 E50S8-500-2-2-24 E50S8-512-2-2-24 E50S8-600-2-2-24 E50S8-800-2-2-24 E50S8-1 E50S8-1 E50S8-1200-2-2-24 E50S8- E50S8- E50S8-2 E50S8-2 E50S8-2500-2-2-24 E50S8-3 E50S8-3600-2-2-24	E50S8-10-2-3-24 E50S8-20-2-3-24 E50S8-30-2-3-24 E50S8-40-2-3-24 E50S8-50-2-3-24 E50S8-60-2-3-24 E50S8-100-2-3-24 E50S8-200-2-3-24 E50S8-300-2-3-24 E50S8-360-2-3-24 E50S8-400-2-3-24 E50S8-500-2-3-24 E50S8-512-2-3-24 E50S8-600-2-3-24 E50S8-800-2-3-24 E50S8-1 E50S8-1 E50S8-1200-2-3-24 E50S8- E50S8- E50S8-2 E50S8-2 E50S8-2500-2-3-24 E50S8-3 E50S8-3600-2-3-24	E50S8-10-4-L E50S8-20-4-L E50S8-30-4-L E50S8-40-4-L E50S8-50-4-L E50S8-60-4-L E50S8-100-4-L E50S8-200-4-L E50S8-300-4-L E50S8-360-4-L E50S8-400-4-L E50S8-500-4-L E50S8-512-4-L E50S8-600-4-L E50S8-800-4-L E50S8-1000-4-L E50S8-1024-4-L E50S8-1200-4-L E50S8-1500-4-L E50S8-1800-4-L E50S8-2000-4-L E50S8-2048-4-L E50S8-2500-4-L E50S8-3000-4-L E50S8-3600-4-L
Autonics	Autonics	Autonics	Autonics
Rotary encoder	Rotary encoder	Rotary encoder	Rotary encoder

型号/规格

E50S8-512-2-2-24

品牌/商标

奥托尼克斯Autonics
