技术参数Technical parameters

单位UNIT

ID7FRGB8S3216

单

  元

模

块

物理点间距Pixel pitch

MM

7.62

模块尺寸Panel size

MM

L243.84XH121.92X14

物理密度Physical density

/M²

17222

像素基色Pixel configuration

R/G/B

1,1,1

驱动方式Driving method

1/8恒流扫描Constant current 1/8scan

LED封装方式LED Encapsulation

DIP

3528

显示分辨率Display resolution

DOTS

32X16=512dots

模块重量Module weight

KG

0.26

模块接口Module port

HUB08

模块工作电压Module working voltage

VDC

5

模块功耗Module consumption

W

18

显

示

屏

*佳视距Option distance

M

7-85

每平米模块数Every square metre module

PCS

33.64

模块视角Viewing angle

Deg.

H120 V120

*大功耗Maximum power

W/ M²

600

驱动器件Driving device

16126

换帧频率Frame Frequency

HZ/S

≥60

刷新频率Refresh frequency

HZ/S

≥400

白平衡亮度Equilibrium brightness

CD/ M²

≥1800

工作环境温度Working environment temperature

⁰C

-20~60

工作环境湿度Working environment humidity

RH

10%～90%

屏体工作电压Display working voltage

VAC

A*6～54HZ，220V&plu*n;15%/110V&plu*n;15%

白场色温Colour temperature

6500K-9500K

灰度/颜色Gray scale/color

≥16.7M color

输入信号Input signal

RF\\ S-Video\\ RGB etc

控制系统Control system

P*V非线性卡nonlinearity card DVI显卡display card Linsn control system

平均无故障时间Mean free error time

HOURS

＞5000

寿命Life

HOURS

100000

杂点率Lampfailure frequency

＜0.0001

*干扰Antijam

IEC801

*Safety

GB4793

*电击Resist the electricity

1500V last 1min无击穿及飞狐No breakdown

屏体重量Steel box weight

KG/ M²

50（标准箱体standard steel box）

漏电电流Earth leakage current

mA

IP等级IPrating

The back IP40，The front IP50

箱体尺寸Steel box size

mm

L975Xh731x100
