供应3M 8309-6000 D-SUB连接器

Insulation
Material: Gl* Filled Polyester (PBT)
Flammability: UL 94V-0
Color: Gray
Contact Material: Copper Alloy
Plating:
Underplating: 100 μ″ [ 2.54 μm ] Nickel
Wiping Area: 30 μ″ [ 0.76 μm ] Gold
Shell
Material: Steel
Plating: Tin
Strain Relief Material: Stainless Steel .016 [ 0.40 ] Thick
Wire Accommodation: 26 and 28 AWG Solid or Stranded
Marking: 3M Logo and Contact Position Numbers
Current Rating: 1 A
Insulation Resistance: > 1 × 109Ω at 500 VDC
Withstanding Voltage: 1000 Vrms at Sea Level
Temperature Rating: -55°C to 105°C
