| No. shape |
TL-N Series |
| Shape shown in Figure |
 |
 |
 |
| Dimension |
 |
 |
 |
DC
6-36V |
三
线
制 |
NPN |
NO |
TL-N5ME1 |
TL-N10ME1 |
TL-N20ME1 |
| NC |
TL-N5ME2 |
TL-N10ME2 |
TL-N20ME2 |
| NO+NC |
|
|
|
| PNP |
NO |
TL-N5MF1 |
TL-N10MF1 |
TL-N20MF1 |
| NC |
TL-N5MF2 |
TL-N20MF2 |
TL-N20MF2 |
| NO+NC |
|
|
|
| Two -wire |
NO |
TL-N5MD1 |
TL-N10MD1 |
TL-N20MD1 |
| NC |
TL-N5MD2 |
TL-N10D2 |
TL-N20MD2 |
AC
90-250V |
Two -wire |
NO |
TL-N5MY1 |
TL-N10MY1 |
TL-N20MY1 |
| NC |
TL-NMY2 |
TL-N10MY2 |
TL-N20MY2 |
|
3-wire |
NO+NC |
|
|
|
|
Detection range |
5mm±10% |
10mm±10% |
20mm±10% |
|
Set distance |
0-4mm |
0-8mm |
0-16mm |
|
Output current |
DC second-line: 100 mA linear 3 - wire and ACTwo-wire: 300mA |
|
Frequency response |
DC200HZAC20HZ |
|
Work environment |
-20℃～+60℃temperature range |
|
Detection of standards |
25*25*1mm(Rail) |
45*45*1mm(Rail) |
60*60*1mm(Rail) | | | |
