**格30W大功率MR16升降压方案XL6006

大功率升压方案，也可做升降压方案！*，*格！

Features
n Wide 5V to 32V Input Voltage Range
n Maximum Boost Output Up to 60V
n 0.22V FB adjustable LED drive current
n Directly drive 16 Series 1W/3W LED at
VIN=24V
n Fixed 180KHz Switching Frequency
n Max. 5A Switching Current Capability
n Up to 94% efficiency
n Excellent line and load regulation
n EN PIN TTL shutdown capability
n Internal Optimize Power MOSFET
n Built in Soft-Start Function
n Built in Frequency Compensation
n Built in Thermal Shutdown Function
n Built in Current Limit Function
n Available in TO263-5L & TO220-5L
package
