L7805ACV-DG 线性稳压器

L7805ACV-DG

线性稳压器 Precision 1.5A Reg 5V Output Dual Gauge

Positive voltage regulator ICs

Description

The L7805ACV-DG L78 series of three-terminal positive regulators is available in TO-220, TO-220FP, D2PAK and DPAK packages and several fixed output voltages, making it useful in a wide range of applications.

These regulators can provide local on-card regulation, eliminating the distribution problems associated with single point regulation. Each type embeds internal current limiting, thermal shut-down and safe area protection, making it essentially indestructible. If adequate heat sinking is provided, they can deliver over 1 A output current. Although designed primarily as fixed voltage regulators, these devices can be used with external components to obtain adjustable voltage and currents.

Features L7805ACV-DG

• Output current up to 1.5 A

• Output voltages of 5; 6; 8; 8.5; 9; 12; 15; 18; 24 V

• Thermal overload protection

• Short circuit protection

• Output transition SOA protection

• 2 % output voltage tolerance (A version)

• Guaranteed in extended temperature range (A version)

型号: L7805ACV-DG

制造商: STMicroelectronics

产品种类: 线性稳压器

RoHS:  无铅环保

安装风格: Through Hole

封装 / 箱体: TO-220-3

输出端数量: 1 Output

极性: Positive

输出电压: 5 V

输出电流: 1 A

输出类型: Fixed

最大输入电压: 40 V

最小工作温度: 0 C

最大工作温度: + 125 C

负载调节: 100 mV

线路调整率: 3 mV

系列: L78

产品: Voltage Regulators

类型: Positive Voltage Regulator

商标: STMicroelectronics

PSRR/纹波抑制—典型值: 68 dB

产品类型: Linear Voltage Regulators

工厂包装数量: 50

子类别: PMIC - Power Management ICs

单位重量: 6 g
